What are those letters stamped on my engine and piston?
6K views
Jan 7, 2025
Solving a Mopar mystery with the help of a Trenton Engine man who worked on the Chrysler, Dodge, Jeep, and Plymouth V8s, sixes, and fours - and why you won't see them on a modern car!
View Video Transcript
0:00
hey everybody this is Dave from motals
0:02
here and I'm here to tell you a little
0:04
story about little markings on your
0:06
pistons and your engine
0:07
blocks on your piston you might notice a
0:10
tiny tiny little marking a tiny little
0:13
letter or on your block you might notice
0:16
a bunch of letters they might go a d c d
0:18
or B CCA or something like that so
0:22
here's the deal is that you know
0:25
everything varies when you make it first
0:27
thing that you learn in statistics class
0:29
including my statistics ICS class is
0:31
that you have a machine and it's making
0:33
the same thing over and over and over
0:35
there is going to be some
0:37
variation and it might be very very
0:39
small variation that you have to measure
0:40
with a microscope or it might be
0:42
relatively big that you can see with a
0:44
hand wielded micrometer or ruler and
0:47
that's the way it used to be with the
0:48
automated Machinery at Trenton engine
0:51
and other Chrysler plants the engine
0:53
plants and everybody's engine plants you
0:56
bore out your cylinder and it'll be
0:59
slightly different depending on the
1:01
state of tooling the weather the
1:04
material you know there's variations in
1:06
the metal there's variations in weather
1:09
all these things they add up and just
1:11
Randomness that we don't know why it's
1:13
happening but it's happening so what
1:15
they did was they said you know these
1:17
variances are so large that if we just
1:19
put any piston into any cylinder some of
1:22
them will barely fit and they'll be
1:24
tight and you know you'll have problems
1:26
there because they'll drag and it'll be
1:28
more resistance and it'll wear out maybe
1:31
uh the engine faster other ones they'll
1:33
be too loose and you'll be blowing oil
1:35
out and you'll have low compression and
1:37
the seals are only meant to have a
1:39
certain range that they'll work in so
1:42
what they did was they marked they
1:44
measured each cylinder and they measured
1:47
each piston and they marked them by
1:49
taking a a die and a hammer and going
1:52
Bam Bam Bam Bam until they had the
1:56
letter now according to uh my source
1:59
here who is a retired uh worker at
2:02
Trenton engine Dave
2:04
vanban that in the uh V8 and slant 6 era
2:09
they ran from a through G's and then if
2:12
they were overboard by 02 in there were
2:15
a whole bunch more classifications so
2:18
they wanted to get things pretty pretty
2:20
close to what they were supposed to be
2:23
and they would Mark both the cylinder
2:27
again and they had Pistons very
2:30
so they'd basically look in the bin you
2:32
know they'd see the engine had a c on
2:35
this cylinder so they'd look in the bin
2:36
for a c-size piston and they'd put it in
2:39
uh when they went on to the
2:41
four-cylinder engines the 2.2 and the
2:43
2.5 the tolerances were better and they
2:45
ran just from a through e and uh he
2:48
thinks that it was about
2:50
0.3 or
2:52
.004 inches that separated each one so
2:56
we're not talking about stuff that you
2:58
would see with your naked eye they had
3:00
to measure it more carefully because
3:02
these are very very small variations but
3:04
they are still very important for your
3:06
engine so Dave said that one of the
3:08
first jobs he had on the V8 assembly
3:10
line was running a teletype machine so
3:12
when a block was loaded onto the
3:14
assembly line he would put in the type
3:16
of engine and the b sizes in order and
3:20
then it would print out in the Piston
3:21
area and they'd load up uh the right
3:24
number of Pistons wrist pins and
3:26
connecting rods assemble them together
3:29
and send them to the line in the
3:30
sequence now apparently uh some people
3:33
would go around looking at the new
3:35
engines and trying to find the ones that
3:37
were overboard or at least had the
3:39
largest variation the largest cylinders
3:42
just again from random variation and
3:44
they would want to use those for racing
3:46
because every little bit helps now over
3:49
time they were able to manufacture with
3:52
much greater Precision you know
3:54
everything got more precise the
3:55
tolerances got smaller and it got to the
3:58
point by the time that Trenton was
4:00
making V6 engines they were able to
4:02
trash the entire system and just have
4:05
one size piston one size cylinder I know
4:07
it was exactly right and move on from
4:09
there so that's progress but if you open
4:12
up your vintage engine or your you know
4:14
your 2.2 engine which I guess today is
4:17
vintage if you open that engine up and
4:19
you see a bunch of letters now you know
4:22
what they're all from and what they and
4:23
why they're there dccd don't try to
4:26
figure out the acronym it's not an
4:28
acronym and don't see you soon at
4:30
motels.com where I hang out
